WHT 27

Art.-Nr. 06-02

Road drier

Machine Type Road drier WHT 27
Engine YANMAR, 6,7 hp (4,9 kW)
Fuel diesel, capacity 3,5 liter
Electrical system 12 V, battery 16 Ah, e-start
Brake system lever controlled parking brake
Wheels front: steel wheel d=200 mm / rear: solid rubber tyre d=200 mm
Air supply fan with 27000 l/min., driven by teeth belt
Operating gas pressure propane gas at 1,5 bar
Gas bottle 11 kg or 33 kg
Equipment electronic ignition control with automatic cut off, air pressure control device, drying head adjustable in height and side position, drying head made of stainless steel with special constructed outlets
Weight without gas bottle approx. 194 kg
Gross weight approx. 262 kg
Dimensions   Length x width x height approx. 1,70 m x 0,60 m x 1,60 m
Right of technical modifications reserved
State of art: 28.01.2015_en
