WHT 10
Art.-Nr. 06-01
Road drier
| Machine Type | Road drier WHT 10 |
| Engine | YANMAR, 7 hp (5,1 kW) |
| Fuel | diesel, capacity 3,5 liter |
| Electrical system | 12 V, battery 16 Ah, e-start |
| Brake system | lever controlled parking brake |
| Wheels | front: steel wheel d=200 mm / rear: solid rubber tyre d=200 mm |
| Air supply | fan with 9910 l/min., driven by teeth belt |
| Operating gas pressure | propane gas at 1,5 bar |
| Gas bottle | 11 kg or 33 kg |
| Equipment | electronic ignition control with automatic cut off, air pressure control device, drying head adjustable in height and side position, drying head made of stainless steel with special constructed outlets |
| Weight without gas bottle | approx. 161 kg |
| Gross weight | approx. 250 kg |
| Dimensions Length x width x height | approx. 1,70 m x 0,60 m x 1,30 m |
Right of technical modifications reserved |
State of art: 01.11.2014_en |
